Detailed Technical Specifications

Product Information

• Product Name: HP ZBook 15u G6 Mobile Workstation
• Model: 15u G6
• Brand: HP
• Series: ZBook (Professional Workstation Series)
• Category: Mobile Workstation Laptop
• Release Year: 2019
• Dimensions: 14.11 x 9.85 x 0.78 inches (358.4 x 250.2 x 19.8 mm)
• Weight: Starting at 4.06 lbs (1.84 kg)

Processor (CPU)

• Model: Intel Core i7-8565U (Whiskey Lake)
• Cores/Threads: 4 cores, 8 threads
• Base Frequency: 1.8 GHz
• Max Turbo Frequency: 4.6 GHz
• Cache: 8MB Intel Smart Cache
• TDP: 15W
• Architecture: 14nm++
• Intel Technologies: Hyper-Threading, Turbo Boost 2.0, vPro, VT-x, VT-d

Display

• Size: 15.6 inches diagonal
• Resolution: 1920 x 1080 (Full HD)
• Panel Type: IPS anti-glare
• Color Gamut: 100% sRGB (typical for workstation models)
• Brightness: 250-300 nits (typical)
• Touch Options: Available as optional configuration
• Privacy Screen: Optional HP Sure View integrated privacy screen

Memory (RAM)

• Capacity: 16GB DDR4 RAM (as configured)
• Type: DDR4-2400 (non-ECC or ECC available)
• Slots: 2 SODIMM slots (user accessible)
• Maximum Supported: Up to 32GB (2x16GB)
• Memory Technology: Dual-channel architecture

Storage

• Primary Storage: 512GB NVMe PCIe SSD
• Interface: PCIe Gen 3.0 x4
• Secondary Storage: Optional 2.5" SATA HDD/SSD bay
• M.2 Slots: 1x M.2 2280 for SSD
• Storage Options: Up to 2TB NVMe SSD + 2TB HDD (dual storage)

Graphics

• Integrated: Intel UHD Graphics 620
• Discrete Option: AMD Radeon Pro WX 3200 (4GB GDDR5)
• Display Outputs: Supports up to 3 external displays (via USB-C/HDMI)
• API Support: DirectX 12, OpenGL 4.6, OpenCL 2.0
• Professional Certification: ISV certified for CAD, DCC applications

Operating System

• Pre-installed: Windows 10 Pro 64-bit
• Recovery: HP Recovery Manager
• Windows Features: BitLocker, Remote Desktop, Group Policy, Hyper-V
• Upgrade Path: Eligible for Windows 11 Pro upgrade (meets requirements)

Connectivity

• Wireless: Intel Wi-Fi 6 AX200 (802.11ax, 2x2) + Bluetooth 5.0
• Ethernet: Realtek RTL8111HSH Gigabit Ethernet
• WWAN: Optional 4G LTE CAT9 (requires SIM slot)

Ports & Interfaces

• USB-C/Thunderbolt 3: 2x (40 Gbps, DisplayPort 1.4, Power Delivery)
• USB 3.1 Gen 1: 2x (Type-A, 5 Gbps)
• HDMI: 1x HDMI 2.0 (4K @ 60Hz support)
• Audio: 1x headphone/microphone combo jack
• Smart Card Reader: Optional
• Media Card Reader: SD/SDHC/SDXC card reader
• Docking: HP UltraSlim Docking connector

Audio

• Speakers: Dual stereo speakers, Bang & Olufsen tuned
• Audio Software: HP Audio Boost, HP Noise Cancellation
• Microphone: Dual array digital microphones
• Audio Codec: Realtek ALC3287

Keyboard & Input

• Keyboard: Full-size, spill-resistant keyboard with numeric keypad
• Backlighting: White LED backlit (adjustable)
• Pointing Device: HP ImagePad with multi-touch gesture support
• Touchpad: Precision touchpad, Microsoft certified

Camera & Security

• Webcam: HP Wide Vision HD camera with dual array microphones
• IR Camera: Optional IR camera for Windows Hello facial recognition
• Fingerprint Reader: Optional fingerprint reader
• Security Chip: TPM 2.0 embedded security chip
• HP Security Features: HP Sure Start Gen5, HP Sure Sense, HP Sure Click, HP Sure Recover

Battery & Power

• Battery Type: 3-cell, 56Wh Li-ion polymer
• Battery Life: Up to 10 hours (MM14)
• Power Adapter: 65W Smart AC adapter (USB-C)
• Fast Charge: 0-50% in approximately 30 minutes
• Battery Warranty: 1-year limited warranty

Durability & Build

• Case Material: Aluminum and magnesium alloy chassis
• MIL-STD Testing: MIL-STD 810G tested (vibration, humidity, temperature, altitude, dust)
• Keyboard: Spill-resistant (up to 330ml)
• Hinge Design: Reinforced metal hinges

Software & Management

• Pre-installed Software: HP Support Assistant, HP BIOS Configuration Utility, HP Client Security Manager
• Management: HP Manageability Integration Kit, Intel vPro (on select configurations)
• Remote Management: HP Velocity, HP Connection Optimizer

Warranty & Support

• Standard Warranty: 3-year limited parts, labor, and onsite service
• Accidental Damage Protection: Optional HP Care Pack
• Support: 24/7 HP premium support available
• ISV Certification: Certified for major CAD, DCC, and engineering applications

Environmental Specifications

• Operating Temperature: 32°F to 95°F (0°C to 35°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Relative Humidity: 10% to 90% (non-condensing)
• Altitude: Up to 15,000 feet (4,572 meters)

Certifications & Compliance

• ENERGY STAR 8.0
• EPEAT Silver
• RoHS compliant
• WEEE compliant
• FCC Class B
• CE Marking
• ISO 9241-307 (pixel defects)

What's in the Box

• HP ZBook 15u G6 Laptop
• 65W USB-C Power Adapter
• Power Cord
• Documentation Kit
• Warranty Card

Professional Use Features

• ISV Certification: Certified for AutoCAD, Revit, SolidWorks, Creo, CATIA, etc.
• Performance Tuning: HP Performance Advisor for workload optimization
• Color Accuracy: Factory-calibrated displays available (Pantone validated)
• Virtual Reality: Not VR Ready (requires more powerful GPU)

Important Notes

• This is a professional workstation, not a gaming laptop
• Graphics performance suitable for CAD, BIM, and light 3D work
• RAM is user-upgradeable via two accessible slots
• Storage can be expanded with additional drives
• Thunderbolt 3 ports support external GPU enclosures
• Windows 10 Pro can be upgraded to Windows 11 Pro
• Battery life varies based on usage, configuration, and power settings
• For heavy 3D rendering, consider ZBook 15/17 with Quadro RTX graphics
