Detailed Technical Specifications

Product Information

• Product Name: HP EliteBook 830 G8
• Model: EliteBook 830 G8
• Brand: HP
• Series: EliteBook 800 Series (Premium Business Laptops)
• Category: Business Ultrabook (13.3-inch)
• Release Year: 2021
• Form Factor: 13.3-inch Clamshell Laptop
• Dimensions: 12.08 x 8.18 x 0.70 inches (306.8 x 207.8 x 17.9 mm)
• Weight: Starting at 2.76 lbs (1.25 kg)
• Color: Natural Silver or Sparkling Black
• Build Quality: Aluminum and magnesium alloy construction, MIL-STD 810H certified

Processor (CPU)

• Model: Intel Core i7-1185G7 (most likely for i7 11th Gen configuration)
• Generation: 11th Generation (Tiger Lake)
• Cores/Threads: 4 cores, 8 threads (with Hyper-Threading)
• Base Frequency: 3.0 GHz
• Max Turbo Frequency: 4.8 GHz (single core)
• All Core Turbo: 4.3 GHz (all 4 cores)
• Cache: 12MB Intel Smart Cache
• Socket: BGA (soldered to motherboard)
• TDP: 12-28W (configurable, typical 15W for ultrabooks)
• Architecture: 10nm SuperFin
• Intel Technologies: Intel Turbo Boost Max 3.0, Hyper-Threading, VT-x, VT-d, AES-NI, Intel vPro
• Other Possible CPUs: i5-1145G7, i7-1165G7, i5-1135G7, i3-1115G4
• Note: vPro variant includes Intel Hardware Shield for enhanced security

Display Options

• Size: 13.3-inch diagonal
• Standard Resolution: Full HD 1920x1080 (FHD)
• Premium Options:
  • FHD IPS Anti-Glare Low Power (1920x1080) - 400 nits, 100% sRGB
  • FHD IPS Touchscreen (1920x1080) - 1000 nits, HP Sure View Reflect integrated privacy screen
  • UHD IPS Anti-Glare (3840x2160) - 550 nits, 100% DCI-P3
• Brightness: 250 nits (standard), 400-1000 nits (premium), 550 nits (UHD)
• Color Gamut: 45% NTSC (standard), 100% sRGB (premium FHD), 100% DCI-P3 (UHD)
• Viewing Angles: 178° horizontal and vertical (IPS technology)
• Bezel: Micro-edge display with 86% screen-to-body ratio
• Touch Options: Available with Corning Gorilla Glass 6 protection
• Privacy Screen: HP Sure View integrated privacy screen (FHD touch models)

Graphics

• Integrated Graphics: Intel Iris Xe Graphics (G7 variant)
• Execution Units: 96 EUs (on i7-1185G7)
• Base Frequency: 400 MHz
• Max Dynamic Frequency: 1.35 GHz
• Video Memory: Shared system memory (dynamic allocation, no dedicated VRAM)
• Max Resolution: 7680x4320 @ 60Hz (DisplayPort over Thunderbolt 4)
• DirectX Support: DirectX 12.1
• OpenGL Support: OpenGL 4.6
• Video Decode: Hardware accelerated 8K H.264, HEVC 10-bit, VP9, AV1 8-bit
• External Display Support: Up to 4 displays total (internal + 3 external via Thunderbolt/docking)
• Graphics Performance: Approximately 2x performance improvement over previous Intel UHD Graphics

Memory (RAM)

• Capacity: 32GB total RAM configuration
• Memory Architecture: Hybrid configuration (16GB soldered + 16GB SODIMM)
• Type: DDR4-3200 (non-ECC)
• Configuration:
  • 16GB soldered to motherboard (not upgradeable)
  • 1x SO-DIMM slot with 16GB module (user upgradeable)
• Maximum Supported: 32GB total (16GB soldered + 16GB SODIMM)
• Memory Technology: Dual-channel architecture (when using matching configurations)
• Speed: 3200MHz (operates at 3200MHz in dual-channel mode)
• Note: 32GB configuration provides excellent performance for virtualization and heavy multitasking

Storage

• Primary Storage: 512GB PCIe NVMe SSD
• Interface: PCIe Gen 4.0 x4 NVMe (or PCIe Gen 3.0 depending on exact configuration)
• Form Factor: M.2 2280
• Storage Slot: 1x M.2 slot (occupied by 512GB SSD)
• Storage Expansion: Can upgrade to larger SSD (up to 2TB typically supported)
• Other Storage Options: 256GB/1TB/2TB PCIe NVMe SSD
• Intel Optane Memory: H20 models with Optane acceleration available on some configurations
• RAID Support: Not available (single drive configuration)
• SSD Performance: Read speeds up to 7000 MB/s, write speeds up to 5000 MB/s (Gen 4.0)

Operating System

• Pre-installed: Windows 10 Pro 64-bit or Windows 11 Pro (depending on purchase date)
• Recovery: HP Cloud Recovery, HP Recovery Manager
• Windows Features: BitLocker, Remote Desktop, Group Policy, Domain Join, Hyper-V, Windows Sandbox
• Windows 11 Compatibility: Fully compatible and certified for Windows 11
• Upgrade Path: Eligible for free Windows 11 Pro upgrade if shipped with Windows 10 Pro
• Linux Options: Certified for Ubuntu, RHEL, SUSE Linux Enterprise

Connectivity

• Wireless: Intel Wi-Fi 6E AX210 (802.11ax, 2x2) + Bluetooth 5.2
• Wi-Fi Speed: Up to 2.4 Gbps (theoretical maximum with Wi-Fi 6E)
• Wi-Fi Bands: 2.4GHz, 5GHz, 6GHz (Wi-Fi 6E)
• Bluetooth: Bluetooth 5.2 with LE Audio support
• Mobile Broadband: Optional 5G (Qualcomm Snapdragon X55) or LTE-Advanced
• Ethernet: No built-in RJ-45 (requires USB-C or docking station adapter)
• Wake-on-LAN: Supported via wireless or wired adapter

Ports & Connectors

• Left Side:
  • 2x Thunderbolt 4 USB-C (40 Gbps, with DisplayPort 1.4, Power Delivery 3.0)
  • 1x USB 3.2 Gen 1 Type-A (5 Gbps)
  • 1x HDMI 2.0b
  • 1x 3.5mm headphone/microphone combo jack
  • 1x Nano SIM slot (optional for mobile broadband)
• Right Side:
  • 1x USB 3.2 Gen 1 Type-A (5 Gbps)
  • 1x AC power connector (optional, some models charge via USB-C only)
  • Optional Smart Card reader
• Docking Support: HP Thunderbolt Dock G2, HP USB-C Dock G5, HP Elite USB-C/AI Dock
• Charging: USB-C Power Delivery 3.0 (up to 100W)

Audio

• Audio System: Audio by Bang & Olufsen
• Speakers: Quad speakers (2 top-firing, 2 bottom-firing) with HP Audio Boost
• Speaker Power: 2W per speaker (total 8W)
• Audio Codec: Realtek ALC3287
• Microphone: Quad array digital microphones
• Audio Features: HP Noise Cancellation Software, DTS:X Ultra, AI-based noise reduction
• 3.5mm Jack: Headphone/microphone combo with headphone amplifier

Camera & Communication

• Webcam: HP Wide Vision 5MP IR camera with temporal noise reduction
• Camera Resolution: 5MP (2560x1920) still, 1080p video at 30fps
• Camera Features: IR sensor for Windows Hello facial recognition, privacy shutter, low-light enhancement
• Optional: HP Presence 5MP camera with automatic framing and look correction
• Microphone: Quad array digital microphones with AI-based noise cancellation
• Video Conferencing: Optimized for Microsoft Teams, Zoom, Cisco Webex with dedicated keys

Keyboard & Input

• Keyboard: Full-size backlit keyboard with spill-resistant design
• Key Travel: 1.5mm
• Backlight: White LED backlight with ambient light sensor
• Special Keys: Dedicated Microsoft Teams key, mute microphone key, programmable function keys
• Pointing Device: Large precision touchpad with multi-touch gesture support
• Touchpad Size: 125 x 81.6 mm
• Touchpad Features: Microsoft Precision drivers, palm rejection, gesture control
• Optional: HP Sure Click secure keyboard (tamper-resistant)

Power & Battery

• Battery Type: 3-cell, 53Wh Li-ion polymer (standard)
• Battery Options: Optional 3-cell, 56Wh long life battery
• Battery Life: Up to 17 hours (MobileMark 2018) with standard battery
• Power Adapter: 65W USB-C Smart AC adapter (included)
• Fast Charging: HP Fast Charge (50% in 30 minutes when powered off)
• Battery Care: Adaptive Battery Optimizer in HP Support Assistant
• Power Features: Modern Standby (instant on/off), USB-C charging from multiple sources

Security Features

• TPM: TPM 2.0 embedded security chip (discrete)
• Fingerprint Reader: Integrated fingerprint reader (optional)
• Smart Card Reader: Optional contact smart card reader
• BIOS Security: HP Sure Start Gen6, Secure Boot, BIOS passwords, hardware root of trust
• HP Security Suite: HP Sure Sense, HP Sure Click, HP Sure Recover, HP Sure Admin, HP Wolf Security
• Intel Security: Intel vPro with Intel Hardware Shield (on vPro models)
• Physical Security: Kensington lock slot, chassis intrusion detection, camera privacy shutter
• Authentication: Windows Hello via IR camera and/or fingerprint reader

Software & Management

• Pre-installed Software: HP Support Assistant, HP Client Security Manager, HP Connection Optimizer
• Management: HP Manageability Integration Kit, Intel vPro with AMT (on vPro models)
• Remote Management: Compatible with HP Manageability Center, Microsoft Endpoint Manager
• Cloud Management: HP Device as a Service (DaaS) ready, Microsoft Autopilot ready
• HP Wolf Security: Includes HP Wolf Pro Security Edition for business protection

Durability & Build Quality

• Military Standard: MIL-STD 810H tested for drops, vibration, humidity, altitude, temperature extremes
• Spill Protection: Spill-resistant keyboard with drainage channels (up to 12 oz)
• Construction: Aluminum chassis with magnesium alloy internal frame
• Hinge Design: 180-degree hinge for lay-flat presentation mode
• Display Protection: Corning Gorilla Glass 6 on touchscreen models
• Keyboard Durability: 10 million keystroke durability testing

Environmental Specifications

• Operating Temperature: 32°F to 95°F (0°C to 35°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Relative Humidity: 10% to 90% (non-condensing)
• Altitude: Up to 15,000 feet (4,572 meters)
• Acoustic Noise: 25 dBA typical (idle), 32 dBA under load

Warranty & Support

• Standard Warranty: 3-year limited warranty (parts, labor, and onsite service)
• Support Hours: 24/7 for critical issues, business hours for others
• Onsite Service: Next business day (in supported locations)
• Extended Warranty: Available up to 5 years
• Accidental Damage Protection: Optional HP Care Pack with ADP

Certifications & Compliance

• ENERGY STAR 8.0 certified
• EPEAT Gold (depending on configuration)
• RoHS compliant
• WEEE compliant
• FCC Class B certified
• CE Marking
• WHQL certified for Windows 10/11
• Intel Evo certified (on some configurations)

What's in the Box

• HP EliteBook 830 G8 laptop
• 65W USB-C Smart AC adapter
• USB-C charging cable
• Documentation kit
• Warranty card

Performance & Business Use

• Target Use: Executive business computing, remote work, enterprise productivity, frequent travel
• Recommended For: Business executives, consultants, sales professionals, IT administrators
• CPU Performance: Excellent for business applications, multitasking, and moderate computational tasks
• Memory Advantage: 32GB provides excellent performance for virtualization, large datasets, and heavy multitasking
• Storage Performance: 512GB NVMe SSD provides fast boot times and application loading with ample storage
• Graphics Performance: Iris Xe Graphics suitable for business applications, 4K video playback, light photo editing
• Portability: Ultra-lightweight design ideal for business travel

Upgrade Potential

• RAM Upgrade: One SO-DIMM slot supports up to 16GB (32GB total with 16GB soldered)
• Storage Upgrade: M.2 slot supports larger NVMe SSDs (up to 2TB)
• Wi-Fi Upgrade: M.2 Wi-Fi card replaceable with newer standards
• Limitations: 16GB RAM soldered, not upgradeable; CPU soldered

Important Notes & Recommendations

• Memory Configuration: 32GB is excellent for virtualization, data analysis, and future-proofing
• Storage: 512GB SSD provides good balance of performance and capacity for business use
• Display: Consider 1000 nits HP Sure View for privacy in public spaces
• Connectivity: Thunderbolt 4 provides excellent expansion options via docking stations
• Security: Comprehensive security suite ideal for sensitive business data
• Compared to 840 G8: 830 G8 is 13.3-inch vs 14-inch, more portable with similar features
• Compared to 830 G7: G8 has 11th Gen processors, Thunderbolt 4, Wi-Fi 6E, improved graphics
• Video Conferencing: 5MP camera and quad microphones provide excellent video call quality
• Battery Life: Actual battery life varies based on usage, display brightness, and power settings
• Value Proposition: Premium business ultrabook with top-tier performance, security, and portability
